* Product solution Model number: BAKTH-ITL0100300020-01

* Product Solution: SH3676010BX+BQ34Z100

* Compatibleinterface: SMBUS

* Battery Type: Li-ion

* Serial number: 10S lithium battery protection board

* Over charge detection voltage(Cell):  4.250V±0.050V

* Over Discharge Detection Voltage(Cell): 2.500V±0.050V

* Over Current Discharge: 15A±5A

* Over Current Charge: 45A±5A

* Discharging Temperature:  -0℃~50℃

* Charge Temperature:  -20℃~60℃

* Max.Discharge Current: 20A

* Max.charge Current: 5A

* Design Certification Requirements: Conform to IEC62133、KC、PSE、UL2054

* Dimension(mm): 120*52*6.85mm
