* Product solution Model number: BAKTH-ITL0080200041-01

* Product Solution: BQ7693000+BQ78350+SH3676010BX+MOT8156T

* Compatibleinterface: SMBUS

* Battery Type: Li-ion

* Serial number: 8S lithium battery protection board

* Over charge detection voltage(Cell):  3.700V±0.050V

* Over Discharge Detection Voltage(Cell): 2.300V±0.050V

* Over Current Discharge: 18A-23A

* Over Current Charge: 18A-23A

* Discharging Temperature:  -20℃~70℃

* Charge Temperature:  -5℃~50℃

* Max.Discharge Current: 10A

* Max.charge Current: 10A

* Design Certification Requirements: Conform to IEC62133、KC、PSE、UL2054

* Dimension(mm): 125*43*7.92mm
