* Product solution Model number: BAKTH-ITL0040100095-01

* Product Solution: BQ4050/BQ40Z50

* Compatibleinterface: SMBUS

* Battery Type: LiFe-PO4/Li-ion

* Serial number: 3S lithium battery protection board

* Over charge detection voltage(Cell):  4.250V±0.025V

* Over Discharge Detection Voltage(Cell): 2.800V±0.025V

* OCD1 Over Current Discharge: 9.0A±0.5A

* OCD2 Over current Discharge: 10.0A±0.5A

* OCC1 Over Current Charge: 5.0A±0.5A

* OCD2 Over current charge: 6.0A±0.5A

* Discharging Temperature:  -40℃~65℃

* Charge Temperature:  -2℃~55℃

* Max.Discharge Current: 8A

* Max.charge Current: 4A

* Design Certification Requirements: Conform to IEC62133、KC、PSE、UL2054

* Dimension(mm): 64*24*11.67mm
