* Product solution Model number: BAKTH-ITL0030010089-01

* Product Solution: BQ4050/BQ40Z50

* Compatibleinterface: SMBUS

* Battery Type: LiFe-PO4/Li-ion

* Serial number: 3S lithium battery protection board

* Over charge detection voltage(Cell):  4.230V±0.025V

* Over Discharge Detection Voltage(Cell): 2.800V±0.025V

* OCD1 Over Current Discharge: 8.0A±0.5A

* OCD2 Over current Discharge: 12.0A±0.5A

* OCC1 Over Current Charge: 3.0A±0.5A

* OCD2 Over current charge: 4.0A±0.5A

* Discharging Temperature:  -20℃~60℃

* Charge Temperature:  0℃~45℃

* Max.Discharge Current: 5A

* Max.charge Current: 2A

* Design Certification Requirements: Conform to IEC62133、KC、PSE、UL2054

* Dimension(mm): A:59.2*22*7.85mm  B:60.8*18.3*3.36mm
