* Product solution Model number: BAKTH-ITL0010120107-01

* Product Solution: R5492N101KL

* Compatibleinterface: Hardware board

* Battery Type: Li-ion

* Serial number: 1S lithium battery protection board

* Over charge detection voltage(Cell):  4.250V±0.030V

* Over Discharge Detection Voltage(Cell): 2.500V±0.100V

* Over Current Discharge: 15A-25A

* Over Current Charge: 7.5A-13.5A

* Discharging Temperature:  /

* Charge Temperature:  /

* Max.Discharge Current: 5A

* Max.charge Current: 12A

* Design Certification Requirements: Conform to IEC62133、KC

* Dimension(mm): 35.3*32.8*2.63mmmm
