* Product solution Model number: ITL0040600108-01

* Product Solution: FT92051BC3-B

* Compatibleinterface: Hardware board

* Battery Type: LifePO4

* Serial number: 4S lithium battery protection board

* Over charge detection voltage(Cell):  3.650V±0.080V

           * 2st Level charge detection voltage(Cell):3.850V±0.050V

* Over Discharge Detection Voltage(Cell): 2.300V±0.050V

* Over Current Discharge: 65A-75A

* Over Current Charge: 10A-16A

* Discharging Temperature:  -23℃~73℃

* Charge Temperature:  -3℃~63℃

* Max.Discharge Current: 60A

* Max.charge Current: 6A

* Design Certification Requirements: Conform to IEC62133、KC

* Dimension(mm): 117.5*56*13.19mm
