* Product solution Model number: BAKTH-ITL0030050128-01

* Product Solution: BQ4050/BQ40Z50

* Compatibleinterface: SMBUS

* Battery Type: Li-ion

* Serial number: 3S lithium battery protection board

* Over charge detection voltage(Cell):  4.280V±0.025V

* Over Discharge Detection Voltage(Cell): 2.800V±0.025V

* OCD1 Over Current Discharge: 3.0A±0.5A

* OCD2 Over Current Discharge: 5.0A±0.5A

           * OCC1 Over Current Charge: 5.0A±0.5A

* OCC2 Over Current Charge: 7.0A±0.5A

* Discharging Temperature:  -17℃~53℃

* Charge Temperature:  -3℃~58℃

* Max.Discharge Current: 3A

* Max.charge Current: 2A

* Design Certification Requirements: Conform to IEC62133、KC、PSE、UL2054

* Dimension(mm): A板 53*26*0.3mm  C板 25.1*14.2*4.04mm
