* Product solution Model number: ITL0020050186-01

* Product Solution: BQ4050+CJAB35N03S

* Compatibleinterface: SMBUS

* Battery Type: Li-ION

* Serial number: 2S lithium battery protection board

* Over charge detection voltage(Cell):  4.250V±0.025V

* Over Discharge Detection Voltage(Cell): 2.800V±0.050V

* OCD1 Over current Discharge: 4.50A±0.5A

* OCD2 Over current Discharge: 7.0A±0.5A

* OCC1 Over Current Charge:3.0A±0.5A

 * OCC2 Over Current Charge:4.5A±0.5A

* Discharging Temperature: -17℃~68℃

* Charge Temperature:  -3℃~42℃

* Max.Discharge Current: 2A

* Max.charge Current: 4A

* Design Certification Requirements: Conform to IEC62133、KC

* Dimension(mm): 67.5*19.5*4.76mm
