* Product solution Model number: BAKTH-ITL0040050189-01

* Product Solution: BQ4050+AON6354

* Compatibleinterface: Hardware board

* Battery Type: Li-ion

* Serial number: 4S lithium battery protection board

* Over charge detection voltage(Cell):  4.250V±0.025V

* Over Discharge Detection Voltage(Cell): 2.500V±0.025V

* 2st Level charge detection voltage: 4.350V±0.050V

* OCD1 Over Current Discharge: 12.0A±0.5A

* OCD2 Over Current Discharge: 15.0A±0.5A

* OCC1 Over Current Charge: 8.0A±0.5A

* OCC2 Over Current Charge: 9.0A±0.5A

* Discharging Temperature:  -16℃~69℃

* Charge Temperature:  -4℃~44℃

* Max.Discharge Current: 5A

* Max.charge Current: 5A

* Design Certification Requirements: Conform to IEC62133、KC

* Dimension(mm): 146*18.65*1.92mm
